The IRONWOOD P600 Thickness Planer is the craftsman’s choice for creating beautiful, professional pieces. With a sturdy cast iron base constructed with (4) heavy-duty jack screws and standard features like the segmented chip breaker and infeed roller, the Ironwood P600 planer ensures accuracy and superior performance above the rest. This machine caters to the American woodworker in offering enhanced engineering designs and superior build construction for long-lasting and trouble-free performance.
| Max width of work piece |
630 mm |
| Max thickness of work piece |
300 mm |
| Min thickness of work piece |
10 mm |
| Max cutting depth |
8 mm |
| Min length of work piece |
220 mm |
| Cutterhead |
Helical |
| Cutterhead Ø |
98 mm |
| Number of knives |
93 |
| Cutting circle |
102 mm |
| Cutterhead speed |
4800 RPM |
| Table width |
685 mm |
| Table length |
870 mm |
| Infeed rollers |
(1) 76 mm roller |
| Outfeed rollers |
(2) 60 mm rollers |
| Table roller |
(2) 68 mm |
| Table adjustment |
Motorized - keypad |
| Table position display |
Digital |
| Variable feed speed |
19 - 39 FPM |
| Cutterhead motor |
10 HP IE3 |
| Feed motor |
1 HP |
| Table raise/lower motor |
1/2 HP |
| Dust requirements |
6" port / 800 CFM |
| Shipping weight |
2100 lbs |
| Electrical connection* |
230V | 3-phase | 60 Hz. |
